● Input Power Supply：AC 260-485V / 46-63Hz
● Output Voltage：DC 200V - 1000V
● Output Power：600kW
● Metering Accuracy：Accuracy Class 1
● Ingress Protection (IP) Rating：IP54 (For outdoor use)
● Ambient Temperature Range：-20℃ to +55℃
● Installation Method：Cabinet Floor-standing
● Cooling Method：Intelligent Air Cooling
● Cable Entry/Exit：Bottom Entry & Exit
