● Contact Rating：7A/20VDC
● Contact Resistance：30mΩ（MAX)500VDC
● Dielectric Withstand Voltage：500VAC/0.5mA-1 Minute
● Jack Diameter：φ6.3 mm
● Center Pin：φ2.0 mm
● Housing Material：High-Temperature Thermoplastic
● Housing Color：Black or by request
● Packaging Type：Blister Box
● EU RoHS Directive 2011/65/EU：RoHS and Halogen-Free Component
